1.The machine adopts improted touching screen on wchich all seetings and operation can be done.
Meanwhile,various product date can be stored in advance,and operator only to select parameters from
the computer while usage.
2.According to different collocations for the machine and different products,the max packing speed is up to
80pcs/min.
3.Constant temperature heat sealing and cutting system is suitable for PE.POF etc,industrial standard shrink
films,the seal is firm and nice,especially applicable for POF film,adjust the conveyor with the head wheel for
packing products of different size.The reliablity is higher and easier to operate it.
4.The front feed in systems speed is adjustable,combines a worktable at the end of the tunnel,makes whole
machine highly automatically without an operator comes true.
5.Hi-speed hot air circulating shrink tunnel adopts roller type conveyor,the rollers are covered by silicone gel
pipe,they roll automatically,also the conveyor can use mesh belt or S.S mesh belt instead of rollers.
When shrink PE film.need not the rollers roll,easy to convert it by the handle at the end of the tunnel.
6.The temperature inside the tunnel is even,suitable for shrink PE.PVC,POF films.
7.The inner container forms hot air circulation inside tunnel,the volume of hot air can be controlled by the air
doors according to the packing requirements for different products.
| Model: | |
|---|---|
| Quantity: | |
friendpack
BF Side Sealing Wrapping Machine
FQL L Bar Sealing Wrapping Machine
TFB Semi Auto Sleeve Wrapping Machine
TFZ Automatic Sleeve Wrapping Machine
Operation panel
The operation panel is simple and clear, using brand electronic components, very durable.
Cutter protection cover
The sealing and cutting part is equipped with a glass protective cover function to strictly ensure the safety of the operator
Imported alloy cutter
The cutter adopts Teflon-coated anti-sticking and high-temperature alloy knife, the sealing line is strong, no cracking, no coking
High-quality photoelectric equipment
The level inspection adopts imported detection photoelectric, which can accurately detect the substance of the packaged article
Dividing triangle
The membrane dividing plate passes through the middle of the double-layer membrane, and the two layers of the double-layer membrane can be adjusted according to the size of the product.
Quality induction
Turn the hand wheel, you can adjust the height of the opening triangular plate, adapt to the product packaging of different heights, the product height limit is 15cm
